Description
|
It is mainly used to test the fatigue performance of metal materials and components under alternating tension and compression load conditions,and can also be used to test the fatigue life and other performance indicators of various components. Equipped with corresponding special fixtures, which can test standard materials, bolts, chains, gears,connecting rods, sucker pipes and other parts or materials (the actual fixtures are subject to the technical agreement configuration table), and are widely used in automobiles, aerospace, and advanced industries. Colleges, scientific research institutes, quality inspection, metallurgy,research and development of new materials and other fields.
Load Capacity :20kN, 100kN, 200kN、300kN 1. Maximum average load (kN): ±100 2. Maximum unidirectional pulsating load (kN): ±100 3. Maximum alternating load (peak kN): 50 4. Test force measurement range 4%~100% F·S 5. Relative error of average load indication: ≤±0.5﹪ 6. Frequency range (Hz): 60～300 (multi-level frequency adjustment) 7. Power of the whole machine: AC 220V 1.5kW 8. Average load fluctuation degree: 0.5﹪F·S 9. Alternating load fluctuation degree: 0.5﹪F·S 10. The maximum distance between the chucks (mm): 700 11. The maximum distance between two columns (mm): 420
|
